100 watt pure sine wave Inverters with battery Charge Controller micro inverter

Model

Rated Power

  100W

peak Power

  200W

DC input voltage

12V/24V/48V

AC output voltage

110VAC / 220VAC

AC output frequency

50Hz/60HZ

AC output waveform

Modified Sine Wave

Waveform Distortion

THD<2%(Linear load)

 Efficiency

 ≥90.5%

No Load Current

≤0.3A

Fuse

12V:2×20A / 24V:2×15A

DC input voltage range

10V-15V or 20V-30V

Low Voltage Alarm

11V+/-0.5V or 21+/-0.5V

Low Voltage Shutdown

10V+/-0.5V or 20V+/-0.5V

Over Voltage Protection

15.5+/-0.5V

Low Voltage Recovery

12+/-0.5V or 24+/-0.5V

Over Voltage Recovery

15V+/-0.5V or 29V+/-0.5V

Protective Function

Low/Over voltage: LED  Red light, automatic recovery

Over load: LED ,Red light ; automatic recovery

Over temperature : LED ,Red light,;automatic recovery

Short circuit: LED ,Red light; automatic recovery

Working Temp.

–10°C—+60°C
